Product Description
Viking Pump - Model GG4197 - Stainless Steel Gear Pump - 4-1062-2243-502
Pump Construction and Capabilities:
| Port Size | 1" |
| Port Type | Class 150 ANSI Flange |
| Port Orientation | Opposite |
| External Material | Stainless Steel |
| Seal Type | Mechanical Seal |
| Seal Elastomer | PTFE |
| Min Flow Rate (GPM) | 0.0 |
| Max Flow Rate (GPM) | 10.0 |
| Max Pressure (PSI) | 200.0 |
| Max Temperature (F) | 225.0 |
| Relief Valve | Relief Valve |
| Gear/Idler Material | 316SS / 770SS |
| Shaft Material | Stainless Steel |
| Idler Pin | Colmonoy Coated |
| Idler Bushing | Carbon Graphite |
| Shaft Bushing | Sealed Ball Bearing |
Downloads:
Viking Pump 4197 Series Catalog Section
Other Details
About Viking Series 4197 Series Internal Gear Pumps
The Viking Series 4197 Series are high-speed internal gear pumps developed for thin to moderate viscosity liquid handling in space-restricted installations. This series operates at motor speed to provide economical pumping solutions for refined fuels, lube oils, lubrication systems, and other industrial fluid transfer applications.
The 4197 Series is tailored for applications requiring flows up to 75 GPM (17 m3/h).
Features include:
- Compact gear pump series to fit tight space constraints
- For corrosion resistance over a wider pH range
- Non-galling gear materials standard for handling thin liquid applications
Typical applications include:
- Compressor Lubrication
- Refined Fuels (e.g., gasoline, diesel)
- Lube Oils and Machinery Lubrication
- Rotating Equipment Lubrication
- General industrial fluid transfer and circulation
| Model | Standard Port Size | Nominal Pump Rating (60hz) GPM | Nominal Pump Rating (60hz) m3/h | Maximum RPM | Maximum Pressure PSI | Maximum Pressure BAR |
|---|---|---|---|---|---|---|
| GG4197 | 1 | 10 | 3 | 1800 | 200 | 14 |
| HJ4197 | 1.5 | 20 | 4.5 | 1800 | 200 | 14 |
| HL4197 | 1.5 | 30 | 7 | 1800 | 200 | 14 |
| AS4197 | 3 | 35 | 8 | 1200 | 200 | 14 |
| AK4197 | 3 | 50 | 11 | 1200 | 200 | 14 |
| AL4197 | 3 | 75 | 17 | 1200 | 200 | 14 |
