Viking Pump - Model SG0550G0V - Ductile Iron Spur Gear Pump - L-0550-1859-506
Pump Construction and Capabilities:
| Port Size | 0.5" |
| Port Type | NPT |
| Port Orientation | Opposite |
| External Material | Ductile Iron |
| Seal Type | Lip Seal |
| Seal Elastomer | FKM |
| Min Flow Rate (GPM) | 0.0 |
| Max Flow Rate (GPM) | 2.0 |
| Max Pressure (PSI) | 450.0 |
| Max Temperature (F) | 350.0 |
| Relief Valve | Relief Valve |
| Shaft Material | Heat Treated Steel |
| Shaft Bushing | Needle Bearings |
Downloads:
Other Details
About Viking SG Series Spur Gear Pumps
The Viking SG Series spur gear pump is a versatile external gear pump designed for high-pressure performance and reliability in demanding industrial applications like pipeline injection, sampling, and oil polishing.
The SG Series accommodates a broad range of liquids and operating conditions, offering durable performance across many flow rates and pressures. It can handle flows up to 190 GPM (719 LPM) with viscosity capabilities from 28 to 1,000,000 SSU (1 to 250,000 cSt) and temperature ranges from -40 °F to +450 °F.
Features include:
- Flexible mounting options include close-coupled or foot-mounted configurations
- High-pressure capability is provided by needle roller bearings, with optional sleeve bearings
- Dual-pump configurations deliver two flow rates from a single drive, reducing system cost and complexity
Typical applications include:
- Pipeline injection
- Pipeline sampling
- Oil polishing
- Refined fuels
- Lube oils
- Rotating equipment lubrication
- Chemical transfer
- Mobile pump carts
| Model | Standard Port (Inches) | Nominal Capacity At 1750 RPM (GPM) | Nominal Capacity At 1750 RPM (LPM | Continuous Pressure* PSI | Continuous Pressure* BAR | Maximum Temp (F) | Maximum Temp (C) |
|---|---|---|---|---|---|---|---|
| SG-0417 | 3/8 in NPT | 0.06 GPM | 0.23 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0418 | 3/8 in NPT | 0.14 GPM | 0.53 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0425 | 3/8 in NPT | 0.18 GPM | 0.68 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0470 | 3/8 in NPT | 0.5 GPM | 1.89 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0518 | 1/2 in NPT | 0.7 GPM | 2.6 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0525 | 1/2 in NPT | 1 GPM | 3.8 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0535 | 1/2 in NPT | 1.4 GPM | 5.3 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0550 | 1/2 in NPT | 2 GPM | 7.6 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0570 | 1/2 in NPT | 2.8 GPM | 10.6 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0510 | 1/2 in NPT | 4 GPM | 15.1 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0514 | 3/4 in NPT | 5.6 GPM | 21.2 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0519 | 3/4 in NPT | 7.6 GPM | 28.8 LPM | 200 PSI | 14 BAR | 350 F | 175 C |
| SG-0528 | 3/4 in NPT | 11.2 GPM | 42.4 LPM | 100 PSI | 7 BAR | 350 F | 175 C |
| SG-0729 | 1 in NPT | 2.8 GPM | 10.6 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0741 | 1 in NPT | 4 GPM | 15.1 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0758 | 1 in NPT | 5.6 GPM | 21.2 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0782 | 1 in NPT | 8 GPM | 30.3 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0711 | 1 in NPT | 11.2 GPM | 42.4 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0716 | 1 in NPT | 16 GPM | 61 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0722 | 1 1/2 x 1 1/4 in NPT | 22 GPM | 83 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-0732 | 1 1/2 x 1 1/4 in NPT | 32 GPM | 121 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-1013 | 1 1/2 in SAE | 25 GPM | 95 LPM | 500 PSI | 34 BAR | 225 F | 105 C |
| SG-1026 | 2 in SAE | 50 GPM | 189 LPM | 500 PSI | 34 BAR | 225 F | 105 C |
| SG-1420 | 2 in SAE | 70 GPM | 265 LPM | 500 PSI | 34 BAR | 225 F | 105 C |
| SG-1436 | 3 in SAE | 125 GPM | 473 LPM | 500 PSI | 34 BAR | 225 F | 105 C |
| SG-1456 | 4 in SAE | 190 GPM | 719 LPM | 190 PSI | 13 BAR | 225 F | 105 C |
| SG-40518 | 1/2 in NPT | 0.7 GPM | 2.6 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-40525 | 1/2 in NPT | 1 GPM | 3.8 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-40535 | 1/2 in NPT | 1.4 GPM | 5.3 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-40550 | 1/2 in NPT | 2 GPM | 7.6 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-40570 | 1/2 in NPT | 2.8 GPM | 10.6 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-40510 | 1/2 in NPT | 4 GPM | 15.1 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-40514 | 3/4 in NPT | 5.6 GPM | 21.2 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-40519 | 3/4 in NPT | 7.6 GPM | 28.8 LPM | 200 PSI | 14 BAR | 350 F | 175 C |
| SG-40528 | 3/4 in NPT | 11.2 GPM | 42.4 LPM | 100 PSI | 7 BAR | 350 F | 175 C |
| SG-40729 | 1 in NPT | 2.8 GPM | 10.6 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-40741 | 1 in NPT | 4 GPM | 15.1 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-40758 | 1 in NPT | 5.6 GPM | 21.2 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-40782 | 1 in NPT | 8 GPM | 30.3 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-40711 | 1 in NPT | 11.2 GPM | 42.4 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-40716 | 1 in NPT | 16 GPM | 61 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-40722 | 1 1/2 x 1 1/4 in NPT | 22 GPM | 83 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-40732 | 1 1/2 x 1 1/4 in NPT | 32 GPM | 121 LPM | 500 PSI | 34 BAR | 350 F | 175 C |
| SG-41013 | 1 1/2 in SAE | 25 GPM | 95 LPM | 500 PSI | 34 BAR | 225 F | 105 C |
| SG-41026 | 2 in SAE | 50 GPM | 189 LPM | 500 PSI | 34 BAR | 225 F | 105 C |
| SG-41420 | 2 in SAE | 70 GPM | 265 LPM | 500 PSI | 34 BAR | 225 F | 105 C |
| SG-41436 | 3 in SAE | 125 GPM | 473 LPM | 500 PSI | 34 BAR | 225 F | 105 C |
| SG-41456 | 4 in SAE | 190 GPM | 719 LPM | 190 PSI | 13 BAR | 225 F | 105 C |
| SG-80518 | 1/2 in NPT | 0.7 GPM | 0.16 LPM | 500 PSI | 34 BAR | 225 F | 105 C |
| SG-80525 | 1/2 in NPT | 1 GPM | 0.23 LPM | 500 PSI | 34 BAR | 225 F | 107 C |
| SG-80535 | 1/2 in NPT | 1.4 GPM | 0.32 LPM | 500 PSI | 34 BAR | 225 F | 107 C |
| SG-80550 | 1/2 in NPT | 2 GPM | 0.45 LPM | 500 PSI | 34 BAR | 225 F | 107 C |
| SG-80570 | 1/2 in NPT | 2.8 GPM | 0.64 LPM | 500 PSI | 34 BAR | 225 F | 107 C |
| SG-80510 | 1/2 in NPT | 4 GPM | 0.91 LPM | 500 PSI | 34 BAR | 225 F | 107 C |
| SG-80514 | 3/4 in NPT | 5.6 GPM | 1.27 LPM | 500 PSI | 34 BAR | 225 F | 107 C |
| SG-80519 | 3/4 in NPT | 7.6 GPM | 1.73 LPM | 500 PSI | 34 BAR | 225 F | 107 C |
| SG-80528 | 3/4 in NPT | 11.2 GPM | 2.54 LPM | 100 PSI | 7 BAR | 225 F | 107 C |
| SG-80741 | 1 in NPT | 4 GPM | 0.91 LPM | 500 PSI | 34 BAR | 225 F | 107 C |
| SG-80758 | 1 in NPT | 5.6 GPM | 1.27 LPM | 500 PSI | 34 BAR | 225 F | 107 C |
| SG-80782 | 1 in NPT | 8 GPM | 1.82 LPM | 500 PSI | 34 BAR | 225 F | 107 C |
| SG-80711 | 1 in NPT | 11.2 GPM | 2.54 LPM | 500 PSI | 34 BAR | 225 F | 107 C |
| SG-80716 | 1 in NPT | 16 GPM | 3.63 LPM | 500 PSI | 34 BAR | 225 F | 107 C |
| SG-80722 | 1 1/2 x 1 1/4 in NPT | 22 GPM | 5.00 LPM | 500 PSI | 34 BAR | 225 F | 107 C |
| SG-80732 | 1 1/2 x 1 1/4 in NPT | 32 GPM | 7.27 LPM | 500 PSI | 34 BAR | 225 F | 107 C |
